Output power factor 0.9, offering more stronger load capability

Online double conversion HF UPS technology with DSP control , excellent performance and comprehensive protections for load and UPS

Wide input range frequency, compatible with almost all kinds of generators

System efficiency above 92%,thanks to the most advanced design bring higher efficiency to save using cost

Battery configuration flexible, 1kVA-24/36v,2kVA-48/72v,3kVA-72/96v etc

EPO function, emergency power off(optional)

Self-diagnosis when UPS start up

Cold start (DC power on)

Compact design and less noise

Lightening and Surge protection 1050J

Fan speed Varies according to load automatically

Standard RS232 interface,( USB ,dry contact,SNMP card optional )

Model
Capacity1kVA // 2kVA // 3kVA
Input
Voltage Range110VAC-288VAC
Frequency Range40Hz～70Hz
PhaseSingle Phase in
Power Factor≥0.99
Output
Voltage Range220V/230V/240V
PhaseSingle Phase out
Frequency Range50Hz +- 0.05
THD (Linear Load)≤2% THD, Linear Load
THD (Non-Linear Load)≤ 5.5% THD, None-linear ≤ 5% // THD, None-linear ≤ 5% // THD, None-linear
Overload Capabilityshutdown after 10Sec; 150%:shutdown after 5Sec 105%～103%= Battery // Inverter = 105%～130%: to bypass after 1 min; 150%: to bypass after 30Sec
Crest Factor3:1
Efficiency94% // 96%
Battery
DC Voltage36VDC // 72VDC // 96VDC
Charger Current12A
Communication Interface
Parallel Port-
Noise Level-
Environment
Temperature-
Storage Temperature-
Other
Standard Unit Net / Gross Weight (kg)10.5 // 21 // 24.5
Long Time Unit Net / Gross Weight (kg)15.5 // 26 // 29.5
Dimension (W×D×H) (mm)144*353*222 // 190*374*336 // 190*426*336
Packing (W×D×H) (mm)164*373*242 // 210*394*356 // 210*446*356
